3D Printing Design

Applying smart design principles to amplify benefits of additive manufacturing

By September 27, 2019
Applying Smart Designs Header

While it’s possible to use additive manufacturing to replicate an existing part that’s produced using traditional methods, it isn’t the best use of additive manufacturing. To maximize a part’s performance, cost savings and material usage, it’s best to design it from the ground up with the unique opportunities and constraints of additive in mind. Or, in other words, you should create your product using design for additive manufacturing (DFAM) principles.

DFAM draws on the same idea as design for manufacturability (DFM) — integrating process planning and product development. But instead of optimizing a product for urethane casting or injection molding, DFAM optimizes a product for production-grade manufacturing with additive technologies by analyzing competing factors to develop the most efficient design.

Additive manufacturing isn’t as simple as hitting print, especially when using DFAM principles to design a part for industrial-grade quality while minimizing production costs. But the resulting parts meet the performance of traditionally manufactured parts while reducing lead times, eliminating tooling costs and maximizing design flexibility. Leveraging DFAM guidelines early on in the product development process allows product design teams to optimize their designs to capture the value of additive manufacturing.

Here are a few common principles of DFAM to consider when leaping from additive manufacturing for prototyping to additive manufacturing for production:

Minimize overhangs and reduce reliance on supports

Each successive slice of your part as it is printing (e.g., in FDM, DMLS, etc.) relies on the layers below it for support. Large overhangs, openings and other features may require additional support during the build to prevent warping and ensure the product achieves its performance tolerances.Parts designed with DFAM principles in mind will be self-supporting, minimizing the need for supporting features which can add cost through material waste and added post-processing needs. And if supports are required, one cost-saving consideration would be to orient the part so that supports are placed in regions that aren’t user-facing, where marks are acceptable. This reduces the sanding and finishing time required in post-processing.

Part orientation

While additive manufactured parts can be built in many orientations, the angle at which a feature is built can affect its tolerances. And because features can only deviate from the spec so much until it affects tolerance limits, it’s important to consider a range of possible orientations early on in the design process. That way, you can identify which orientation is best-suited for producing your part.

Consolidate multi-part assemblies

It’s difficult to produce complex shapes with traditional manufacturing, which can necessitate creating some products as multi-part assemblies. If you are transitioning your product from traditional to additive manufacturing, it can often be consolidated into fewer parts to significantly reduce assembly costs. When Steelcase designed an arm cap using for additive manufacturing, for example, we transformed a three-part assembly into one uninterrupted part with multiple functional zones

Leveraging generative design to optimize your part

The unique geometries possible through additive processes allows product designers to leverage generative design tools (e.g., topology optimization or lattice structures) to optimize the structure of your part based on hundreds of variables. And because lattices allow you to precisely tune the strength and material density in different regions of a part, one contiguous part can meet different performance requirements in different regions.

incorrect and correct use


The most important additive manufacturing design consideration

None of these guidelines address one of the biggest obstacles to transitioning to production-grade additive manufacturing: An additive manufacturing product design skills gap. Because of this gap, the most important design guideline is to align yourself with additive manufacturing product design experts at the outset of any DFAM project. They will recommend design modifications that will optimize the cost and performance of your product. And they’ll understand how to drive efficiencies at the supply chain level through on-demand production and virtual warehousing. The sooner you involve expert AM design and engineering support, the greater the benefits you stand to earn with your switch to additive.
