Stereolithography (SLA) 3D Printing Service

Is your part file ready to go?
Want to talk about your project?

SLA is a type of photopolymerization capable of producing parts with an excellent surface finish and small feature resolution. While SLA is not typically suitable for high-performance applications, its intricate and accurate detailing make it a popular option for prototypes. Our factory uses Formlabs Form 3 SLA 3D printers.

Producing parts with SLA

Build volume

• 335 × 200 × 300 mm
• 13.2 × 7.9 × 11.8 in

Min. feature size

• The minimum feature size is different for each resin, but we are able to achieve complex and aggressive geometry.

Lead time

• Get your prototypes in as little as seven days. Production or high volume runs will be examined on a case by case basis.

Material

Color

Hardness (post-cure)

Description

Surgical guideClear orange67D• Biocompatible
• Sterilizable and solvent safe
• Good material properties
ClearClear82D• Able to make clear parts with intricate features
• Not optically clear but perfect to let light pass through and achieve some
RigidWhite89D• Strong, stiff, and resistant to bending
• Soft matte white finish
Tough 2000Gray81D• Strong and sturdy
• Good for prototypes
• Resistant to bending
Tough 1500Medium Gray76D• Resilient rigid resin
• Good for stiff but pliable parts that spring back into shape
ElasticClear50A• Springy, bendable and stretchable
• Will return quickly to original shape
FlexibleBlack80-85A• Dampening properties
• Good for cushioning and soft touch areas
• Stronger mechanical properties than Elastic
DurableTranslucent, Clear• Pliable, impact resistant, lubricious
• Ideal for high wear areas or rigid parts that need to be pliable
WhiteWhite• Matte white
• Able to achieve precise details
• Good for general prototypes or aesthetic parts
ColorSelect colors available• Color resin
• Able to achieve precise details
• Good for general prototypes or aesthetic parts
• Only available for production qty orders
High TempTranslucent Orange• Detailed precise prototypes
• Able to withstand temperatures up to 238 °C

FINISHING/POST-PROCESSING OPTIONS

PaintingBead blastingSmoothingPress-fit inserts
Digital texturingHydrographicsLaser surface decorating / etching

NEED INFORMATION ON design guidelines, pricing, and lead times?

Axial 3D 228x68 1

16% reduction in recovery times

Made possible with Fast radius

Every day we’re working with the world’s leading product manufacturers to make the parts that matter most to their businesses.

Common SLA Applications

SLA 3D printing produces parts with small feature resolution and excellent surface finish, making it a good technology for applications where details are important.

Master patterns

High dimensional accuracy for precise patterns.

FR Capabilities Icon Libary MasterPatterns

Scale models

Capable of producing intricate details with high-resolution.

FR Capabilities Icon Libary ScaleModels

Prototypes

Excellent resolution, small feature size, and finish.

FR Capabilities Icon Libary Prototyping
